3M SJ5327 Datasheet 3M SJ5327

CONTACT REP
Information provided by Gluespec

  • Description for 3M SJ5327

    The urethane is a durable, resilient elastomer. The aggressive, high tack pressure sensitive adhesive is protected with a release liner making application fast and easy.

    *See Terms of Use Below

    Brand Bumpon
    Chemical Resistance Isopropyl Alcohol, Chemical Resistance: Excellent Solvent Resistance, Chemical Resistance: Hydrochloric Acid, Chemical Resistance: Fluid Resistance: Detergent in water resistance, Auto Oil, Chemical Resistance: Toluol, Chemical Resistance: Fluid Resistance: Ammonia in water resistance, Bleach, Chemical Resistance: Lacquer Thinner, Heptane, Diesel Fuel
    Application Type Bond
    1 Part or 2 Part 1-Part
    Material Form Bumpons
    Substrate Acrylic, Aluminum, Glass, Metal, Polycarbonate, Stainless Steel , Low Surface Energy Acrylic (A-20), ABS, High Surface Energy Acrylic (A-20), Low Surface Energy Acrylic (A-20)
    Industry Desk top, Automotive, Transportation, Keyboards, Computers, Handheld electronic devices, Stops for cabinet doors, Dispensers, Speakers, Clocks, Scales, Foot pedals, Telephones, Electronic cabinetry
    Manufacturer 3M
    Chemistry Acrylic, Plasticizer-free, Polyurethane
    Cure Method Pressure-Sensitive
    Color Black, Brown, Gray, Transparent, White
    Aging Resistance Aging resistance
    High Temperature Resistance (°C) 66, 107
    Low Temperature Resistance (°C) -34
    Other Resistance Excellent skid resistance, marring, staining
    Elastomeric Resilient Elastomer
    Shore M Hardness 75

  • Technical Data for 3M SJ5327

    *See Terms of Use Below

    Overview
    • Chemical Resistance
      • Chemical Resistance : Fluid Resistance : Water Resistance - Detergent in water resistance, Ammonia in water resistance
      • Chemical Resistance - Bleach, Diesel Fuel, Auto Oil, Isopropyl Alcohol, Heptane
      • Chemical Resistance : Relative Solvent Resistance - Excellent Solvent Resistance, Toluol, Lacquer Thinner
      • Chemical Resistance : Acid Resistance - Hydrochloric Acid
    • Application Type
    • 1 Part or 2 Part
      • 1-Part
    • Material Form
      • Bumpons
    • Substrate
    • Industry
      • Transportation
      • Keyboards
      • Storage & Graphics - Computers
      • Telecom / Datacom - Handheld electronic devices
      • Automotive
      • Electronics - Dispensers, Speakers, Clocks, Scales, Foot pedals, Telephones, Electronic cabinetry, Desk top
      • Speakers - Feet on the bottom of speakers
      • Appliances - Bottom of small appliances
      • Construction Door - Stops for cabinet doors
      • Other - Spacers for picture frames to provide alignment, For auto glass as an aid in assembly, Protectors for stacked glass and metal sheets, Stops for cabinet drawers, Stops for cabinet lids
    • Chemistry
    • Application Method
      • Contact
    • Cure Method
      • Pressure Sensitive (min) - Pressure-Sensitive
    • Color
      • Black
      • Brown
      • Clear / Transparent - Transparent
      • Gray
      • White
    • Brand
      • Bumpon
    Specifications
    Bond Strength
    General Bond Strength (psi) Poor, Fair Test Method
    Peel Strength (piw) Poor, Good, 3 (oz. Per 1/2 inch), 11 (oz. Per 1/2 inch), 25 (oz. Per 1/2 inch), 25 (oz. Per 1/2 inch), 25 (oz. Per 1/2 inch) Test Method
    Shear Strength (psi) Excellent, Excellent, Excellent, Excellent Test Method
    Tensile Strength (psi) 740 Test Method
    Material Resistance
    Aging Resistance Aging resistance
    Abrasion Resistance Abrasion resistance Test Method
    High Temperature Resistance (°C) 66, 107
    Impact Resistance Impact Resistance
    Low Temperature Resistance (°C) -34
    Other Resistance Excellent skid resistance, marring, staining Test Method
    Hardness
    Elastomeric Resilient Elastomer
    Shore M Hardness 75 Test Method
    Elongation (%) 65 Test Method
    Business Information
    Shelf Life Details Store in original cartons at 60° to 80°F (16° to 27°C) and 40 to 50% relative humidity.;To obtain best performance, use this product within 18 months from date of manufacture.
    Shelf Life Type From date of manufacture.
    Shelf Life (mon) 18
    Not Good For
    Don't Use With low surface energy/substrates, polypropylene, polyethylene

  • Best Practices for 3M SJ5327

    *See Terms of Use Below

    1. Surface Preparation

      To obtain maximum adhesion, surfaces must be unified, dry, and free of contaminants. Surface contact is essential to adhesive performance. To maximize contact on a substrate: Clean surfaces with low strength solvent such as isopropyl alcohol (rubbing alcohol) or heptane.

      Note: Be sure to follow the manufacturer’s precautions and directions for use when using solvents.

    2. Application

      Apply firm pressure to help increase the cold flow and contact of the adhesive with the substrate

    3. Curing

      Allow time (dwell) to increase the surface contact and adhesion (see illustrations below).

  • Comparable Materials for 3M SJ5327

    *See Terms of Use Below

    Spec Engine® Results

    • 3M
      SJ5306(3M)

      The urethane is a durable, resilient elastomer. The aggressive, high tack pressure sensitive adhesive is protected with a release liner making application fast and easy.

    • 3M
      SJ5302(3M)

      The urethane is a durable, resilient elastomer. The aggressive, high tack pressure sensitive adhesive is protected with a release liner making application fast and easy.

    • 3M
      SJ5303(3M)

      The urethane is a durable, resilient elastomer. The aggressive, high tack pressure sensitive adhesive is protected with a release liner making application fast and easy.

    • Compare All
  Download Technical Data Sheet   Save This Material   Compare View Saved Items

Popular Articles

Testing the effectiveness of surface treatments

Read Article

What Projects Require Custom Adhesive Formulations and Why?

Read Article

Infographic: ENSURING A STRONG BOND - 6 Basic Methods of Surface Preparation

Read Article

Characteristics of MMAs

Read Article

Sponsored Articles

Unique Advantages of Contact Adhesives

Read Article

Using LOCTITE® 454™ is a Valid Option for Engineers Working with a Wide Variety of Materials

Read Article

Sylgard 184 by DOW is the Top Choice for a Transparent, Silicone Encapsulant. Read Why:

Read Article

Case Study: Creating reliable, corrosion-free bonds with LORD® 406 acrylic adhesive

Read Article

Featured Ads

Top Catalog Pages for 3M SJ5327

All 3M Materials
View Now

Gluespec Poll

What level of expertise do you have in specialty chemicals like adhesives, sealants, conformal coatings, etc.?
General Bond Strength Test Methods
General Bond Strength Substrate Test Method
Poor Low Surface Energy Acrylic (A-20) Acrylic (A-20) - Used in the construction of 3M™ Bumpon Protective Product Series SJ-5200, SJ-5300, and SJ-5400, this high strength adhesive system provides excellent shear strength properties. The adhesive has the capability of providing excellent adhesion to many high surface energy substrates such as metals, ABS,_x00D_ polycarbonate, and acrylic. When adhesion is required on low surface energy/substrates (e.g., polypropylene, polyethylene, etc.), acrylic-based adhesives do not perform as well as rubber-based adhesives
Fair High Surface Energy Acrylic (A-20) Acrylic (A-20) - Used in the construction of 3M™ Bumpon Protective Product Series SJ-5200, SJ-5300, and SJ-5400, this high strength adhesive system provides excellent shear strength properties. The adhesive has the capability of providing excellent adhesion to many high surface energy substrates such as metals, ABS, polycarbonate, and acrylic. When adhesion is required on low surface energy/substrates (e.g., polypropylene, polyethylene, etc.), acrylic-based adhesives do not perform as well as rubber-based adhesives
Peel Strength Test Methods
Peel Strength Type Substrate Test Method
Poor Low Surface Energy Acrylic (A-20) Acrylic (A-20) - Used in the construction of 3M™ Bumpon Protective Product Series SJ-5200, SJ-5300, and SJ-5400, this high strength adhesive system provides excellent shear strength properties. The adhesive has the capability of providing excellent adhesion to many high surface energy substrates such as metals, ABS, polycarbonate, and acrylic. When adhesion is required on low surface energy/substrates (e.g., polypropylene, polyethylene, etc.), acrylic-based adhesives do not perform as well as rubber-based adhesives
Good High Surface Energy Acrylic (A-20) Acrylic (A-20) - Used in the construction of 3M™ Bumpon Protective Product Series SJ-5200, SJ-5300, and SJ-5400, this high strength adhesive system provides excellent shear strength properties. The adhesive has the capability of providing excellent adhesion to many high surface energy substrates such as metals, ABS, polycarbonate, and acrylic. When adhesion is required on low surface energy/substrates (e.g., polypropylene, polyethylene, etc.), acrylic-based adhesives do not perform as well as rubber-based adhesives
3 (oz. Per 1/2 inch) 90° Peel Adhesion Polypropylene Acrylic A-20, 3M Test Method TM-2011, 72 hour dwell, 1/2 inch wide samples pulled at 12 inches per minute. Testing completed using Bumpon Resilient Rollstock products SJ5816, SJ6016, and SJ6216, which use the same adhesive system as the molded series products.
11 (oz. Per 1/2 inch) 90° Peel Adhesion Polystyrene Acrylic A-20, 3M Test Method TM-2011, 72 hour dwell, 1/2 inch wide samples pulled at 12 inches per minute. Testing completed using Bumpon Resilient Rollstock products SJ5816, SJ6016, and SJ6216, which use the same adhesive system as the molded series products.
25 (oz. Per 1/2 inch) 90° Peel Adhesion ABS Acrylic A-20, 3M Test Method TM-2011, 72 hour dwell, 1/2 inch wide samples pulled at 12 inches per minute. Testing completed using Bumpon Resilient Rollstock products SJ5816, SJ6016, and SJ6216, which use the same adhesive system as the molded series products.
25 (oz. Per 1/2 inch) 90° Peel Adhesion Stainless Steel Acrylic A-20, 3M Test Method TM-2011, 72 hour dwell, 1/2 inch wide samples pulled at 12 inches per minute. Testing completed using Bumpon Resilient Rollstock products SJ5816, SJ6016, and SJ6216, which use the same adhesive system as the molded series products.
25 (oz. Per 1/2 inch) 90° Peel Adhesion Aluminum
Tensile Strength Test Methods
Tensile Strength Test Method
740 psi ASTM-D412, Die A
Shear Strength Test Methods
Shear Strength Type Substrate Test Temperature Test Method
Excellent Dynamic shear strength Acrylic (A-20) Acrylic (A-20) - Used in the construction of 3M™ Bumpon Protective Product Series SJ-5200, SJ-5300, and SJ-5400, this high strength adhesive system provides excellent shear strength properties. The adhesive has the capability of providing excellent adhesion to many high surface energy substrates such as metals, ABS,_x00D_ polycarbonate, and acrylic. When adhesion is required on low surface energy/substrates (e.g., polypropylene, polyethylene, etc.), acrylic-based adhesives do not perform as well as rubber-based adhesives.
Excellent Static Shear Strength Acrylic (A-20) 25°C Acrylic (A-20) - Used in the construction of 3M™ Bumpon Protective Product Series SJ-5200, SJ-5300, and SJ-5400, this high strength adhesive system provides excellent shear strength properties. The adhesive has the capability of providing excellent adhesion to many high surface energy substrates such as metals, ABS,_x00D_ polycarbonate, and acrylic. When adhesion is required on low surface energy/substrates (e.g., polypropylene, polyethylene, etc.), acrylic-based adhesives do not perform as well as rubber-based adhesives.
Excellent Static Shear Strength Acrylic (A-20) 49°C Acrylic (A-20) - Used in the construction of 3M™ Bumpon Protective Product Series SJ-5200, SJ-5300, and SJ-5400, this high strength adhesive system provides excellent shear strength properties. The adhesive has the capability of providing excellent adhesion to many high surface energy substrates such as metals, ABS, polycarbonate, and acrylic. When adhesion is required on low surface energy/substrates (e.g., polypropylene, polyethylene, etc.), acrylic-based adhesives do not perform as well as rubber-based adhesives.
Excellent Static Shear Strength Acrylic (A-20) 70°C Acrylic (A-20) - Used in the construction of 3M™ Bumpon Protective Product Series SJ-5200, SJ-5300, and SJ-5400, this high strength adhesive system provides excellent shear strength properties. The adhesive has the capability of providing excellent adhesion to many high surface energy substrates such as metals, ABS, polycarbonate, and acrylic. When adhesion is required on low surface energy/substrates (e.g., polypropylene, polyethylene, etc.), acrylic-based adhesives do not perform as well as rubber-based adhesives.
Abrasion Resistance Test Methods
Abrasion Resistance Test Method
Abrasion resistance ASTM-C501, Taber H18, 1kg) g/1000 cycles
Other Resistance Test Methods
Other Resistance Test Method
Excellent skid resistance
marring
staining 3M-24 hours @ 158°F against white paint 7 days exposed to UV
Dielectric Strength Test Methods
Dielectric Strength Test Method
Elongation Test Methods
Elongation Test Method
65 % ASTM-D412, Die A, These properties were run on sheet material from the same materials as the individual Bumpon products
Shore M Hardness Test Methods
Shore M Hardness Shore Hardness Test Method
75 Shore M Hardness, ASTM-D2240
