Bostik 2200 TS Datasheet Bostik 2200 TS

CONTACT REP
Information provided by Gluespec

  • Description for Bostik 2200 TS

    A one-component, moisture curing, adhesive/sealant based upon Bostik Hybrid Technology.

    *See Terms of Use Below

    Application Type Bond, Seal
    1 Part or 2 Part 1-Part
    Material Form Paste
    Substrate Pre painted aluminum, Pre painted metal, Steel, Galvanized Steel, Galvanized Steel
    Industry Sidewall seams in transportation vehicles, Truck trailers, Seams and gap filling for RV’s, Truck trailers, HVAC equipment, Waterproofing rivet seams, Seam sealing, Joints constructed of pre-painted metal, Sidewall seams in transportation equipment, Livestock / grain trailers, Corrosion prevention of rivet heads, Joints constructed of pre-painted aluminum, Transportation, Seams and gap filling for motor-homes
    Manufacturer Bostik
    Chemistry Solvent-free, free of alcohols, xylene, MEK, acetone
    Cure Method Moisture
    Cure Temperature (°C) 25
    Cure Time (min) 1,440, 10,080
    High Temperature Resistance (°C) 107
    Low Temperature Resistance (°C) -40

  • Technical Data for Bostik 2200 TS

    *See Terms of Use Below

    Overview
    • Application Type
    • 1 Part or 2 Part
      • 1-Part
    • Material Form
      • Paste
    • Substrate
      • Metal - Pre painted metal
      • Aluminum - Pre painted aluminum
      • Steel
      • Galvanized - Galvanized Steel
      • Galvanized Steel
      • Other - Luaun
    • Industry
      • Transportation - Sidewall seams in transportation equipment, Sidewall seams in transportation vehicles, Seams and gap filling for motor-homes
      • Other Transportation - Roof rails
      • Trucks - Truck trailers
      • Recreational Vehicles - Seams and gap filling for RV’s
      • Trailer - Livestock / grain trailers, Truck trailers
      • Rivet - Waterproofing rivet seams, Corrosion prevention of rivet heads
      • Seam - Seam sealing
      • HVAC - HVAC equipment
      • Joints - Joints constructed of pre-painted metal, Joints constructed of pre-painted aluminum
      • Other - Gap filling
    • Chemistry
    • Application Method
      • Caulking gun - manual or pneumatic caulking dispenser, manual caulk gun
    • Cure Method
      • Moisture / Condensation Cure - Moisture
    Specifications
    Cure Specs
    Cure Temperature (°C) 25
    Cure Time (min) 1,440, 10,080
    Tack Free Time (min) Fast, 30 to 40
    Work / Pot Time (min) 30 to 40
    Thixotropic Medium thixotrophy
    Bond Strength
    Shear Strength (psi) 230, 214 Test Method
    Tensile Strength (psi) 253 Test Method
    Material Resistance
    UV Resistance Excellent
    High Temperature Resistance (°C) 107
    Low Temperature Resistance (°C) -40
    Hardness
    Shore A Hardness 55 Test Method
    Elongation (%) 200 Test Method
    Modulus (psi) 66, 116, 189 Test Method
    Other Properties
    % Solids (%) 100
    Business Information
    Shelf Life Details Twelve months from date of maufactured when stored below 80°F (27°C).
    Shelf Life Type From date of manufacture
    Shelf Life (mon) 12

  • Best Practices for Bostik 2200 TS

    *See Terms of Use Below

    1. Surface Preparation

      Substrates should be free of all loose contamination, greases, oils, etc. Use Isopropyl alcohol or other approved solvent for substrate pretreatment.

      Temperatures of substrate must be above 40°F. Recommended substrate and product application temperatures are between 55°F and 100°F.

    2. Application

      Application—Cartridge: Cut nozzle to desired bead size opening and puncture the inner foil seal. Place cartridge into either a manual or pneumatic caulking dispenser. Apply appropriate pressure to install 2200 TS so as to assure full contact (surface wetting) to promote sealing and adhesion performance. Tool and finish applied 2200 TS immediately to promote best mechanical adhesion and cure appearance. Use water or soapy water solution for tooling compound.

      Application—Sausage: Cut tip to desired shape and diameter. Place sausage into a manual or pneumatic caulking dispenser. Apply appropriate pressure to install 2200 TS so as to assure full contact (surface wetting) to promote sealing and adhesion performance. Tool and finish applied 2200 TS immediately to promote best mechanical adhesion and cure appearance. Use water or soapy water solution for tooling compound.

    3. Clean-Up

      Uncured 2200 TS can be easily removed from hands, tools and substrates using Bostik® Hand & Tool Towels.

  • Comparable Materials for Bostik 2200 TS

    *See Terms of Use Below

    Spec Engine® Results

  Download Technical Data Sheet   Save This Material   Compare View Saved Items

Popular Articles

Testing the effectiveness of surface treatments

Read Article

Anaerobic Adhesives

Read Article

Infographic: ENSURING A STRONG BOND - 6 Basic Methods of Surface Preparation

Read Article

What Are the Differences Between Adhesives and Sealants?

Read Article

Sponsored Articles

Unique Advantages of Contact Adhesives

Read Article

Using LOCTITE® 454™ is a Valid Option for Engineers Working with a Wide Variety of Materials

Read Article

Sylgard 184 by DOW is the Top Choice for a Transparent, Silicone Encapsulant. Read Why:

Read Article

Case Study: Creating reliable, corrosion-free bonds with LORD® 406 acrylic adhesive

Read Article

Featured Ads

Top Catalog Pages for Bostik 2200 TS

All Bostik Materials
View Now
HVAC
View Now
Trailer
View Now
Rivet Bonding
View Now

Gluespec Poll

What level of expertise do you have in specialty chemicals like adhesives, sealants, conformal coatings, etc.?
Tensile Strength Test Methods
Tensile Strength Cure Time Cure Temperature Cure Humidity
253 psi 10,080 min 25°C 1 %
Shear Strength Test Methods
Shear Strength Type Cure Time Cure Temperature Cure Humidity Substrate Test Method
230 psi Lap Shear strength 10,080 min 25°C 50 % Luaun 0.062-inch gap, 1-inch overlap, speed 2 inches/min,to break,after 7 days ambient cure at 77°F and 50% RH
214 psi Lap Shear strength 10,080 min 25°C 50 % Galvanized Steel 0.062-inch gap, 1-inch overlap, speed 2 inches/min.,to break, after 7 days ambient cure at 77°F and 50% RH
Elongation Test Methods
Elongation Test Method
200 % Break, after 7 days ambient cure at 77°F and 50% RH
Modulus Test Methods
Modulus Test Method
66 psi @ 25% Elongation, after 7 days ambient cure at 77°F and 50% RH
116 psi @ 50% Elongation, after 7 days ambient cure at 77°F and 50% RH
189 psi @ 100% Elongation, after 7 days ambient cure at 77°F and 50% RH
Shore A Hardness Test Methods
Shore A Hardness Shore Hardness Test Method
55 after 7 days ambient cure at 77°F and 50% RH
