Loxeal 3439 Datasheet Loxeal 3439

CONTACT REP
Information provided by Gluespec

  • Description for Loxeal 3439

    Loxeal 3439 is a 1-Part Pressure Sensitive Urethane methacrylate Liquid used to Adhere Ceramics, Ferrites and Metals

    *See Terms of Use Below

    Chemical Resistance Chemical resistance
    Application Type Bond
    1 Part or 2 Part 1-Part
    Material Form Liquid
    Substrate Ceramics, Metals, Ferrites
    Manufacturer Loxeal
    Chemistry Urethane methacrylate, Acid free, Urethane methacrylate, Toughened, Urethane methacrylate
    Cure Method Pressure Sensitive, Room Temperature
    Cure Temperature (°C) 25, 25
    Gap Fill (in) 0.002
    Cure Time (min) Fast, 10 to 20, 1,440
    Viscosity (cPs) 600 to 1,000
    Color Transparent
    High Temperature Resistance (°C) 165
    Low Temperature Resistance (°C) -55

  • Technical Data for Loxeal 3439

    *See Terms of Use Below

    Overview
    • Chemical Resistance
      • Chemical Resistance
    • Application Type
    • 1 Part or 2 Part
      • 1-Part
    • Material Form
      • Liquid
    • Substrate
    • Industry
      • Industrial - Ideal for high speed assembly production lines, Structural adhesive
    • Chemistry
      • Toughened
      • Acrylated Urethane - Urethane methacrylate
      • Acrylic - Urethane methacrylate
      • Other - Acid free
      • Polyurethane - Urethane methacrylate
    • Cure Method
      • Pressure Sensitive (min) - Pressure Sensitive
      • Room Temperature / Air Dry - Room Temperature
    • Color
      • Clear / Transparent - Transparent
    Specifications
    Cure Specs
    Cure Temperature (°C) 25, 25 Test Method
    Gap Fill (in) 0.002
    Cure Time (min) Fast, 10 to 20, 1,440 Test Method
    Viscosity (cPs) 600 to 1,000 Test Method
    Fixture or Handling Strength Time (min) 0.33 to 0.83 Test Method
    Bond Strength
    Shear Strength (psi) Good, 2,901 to 4,351 Test Method
    Impact Strength (psi) Good, 18 - 28 (kJ/ m2) Test Method
    Tensile Strength (psi) 2,176 to 3,626, 3,626 to 5,076 Test Method
    Material Resistance
    Environmental Resistance Environmental resistance
    High Temperature Resistance (°C) 165
    Low Temperature Resistance (°C) -55
    Hardness
    Elongation (%) 20 to 50 Test Method
    Business Information
    Shelf Life Details 1 year in original unopened packaging.; Keep product in a cool and dry room not above +25°C (avoid direct light exposure).
    Shelf Life Temperature (°F) 77
    Shelf Life (mon) 12

  • Best Practices for Loxeal 3439

    *See Terms of Use Below

    1. Surface Preparation

      Clean with Loxeal Cleaner 10 and allow to dry (water and grease may prevent adhesion on the parts) before assembling.

    2. Application

      Apply Activator to one surface and adhesive to the other. Press the parts until handling strength is achieved.

      For gaps larger than 0,5mm apply Activator to both surfaces, then apply the adhesive to one surface and assemble.

    3. Mixing

      No mixing required.

    4. Curing

      Allow the parts at least 24 hours to full cure before disturbing them.

    5. Clean-Up

      Clean the excess adhesive with an organic solvent.

  • Comparable Materials for Loxeal 3439

    *See Terms of Use Below

    Spec Engine® Results

    • PermaBond
      TA437(PermaBond)

      A single component structural acrylic adhesive designed primarily for bonding metals, ferrites and ceramics. This product provides high strength, tough, durable bonds with good impact resistance.

    • Loxeal
      3459(Loxeal)

      Loxeal 3459 is a 1-Part Pressure Sensitive Urethane methacrylate Gel used to Adhere Ceramics, Ferrites and Metals

    • Compare All
  Download Technical Data Sheet   Save This Material   Compare View Saved Items

Popular Articles

Infographic: ENSURING A STRONG BOND - 6 Basic Methods of Surface Preparation

Read Article

Instant Adhesives Guide

Read Article

Testing the effectiveness of surface treatments

Read Article

Electronic Component Adhesives Guide

Read Article

Sponsored Articles

Unique Advantages of Contact Adhesives

Read Article

Using LOCTITE® 454™ is a Valid Option for Engineers Working with a Wide Variety of Materials

Read Article

Sylgard 184 by DOW is the Top Choice for a Transparent, Silicone Encapsulant. Read Why:

Read Article

Case Study: Creating reliable, corrosion-free bonds with LORD® 406 acrylic adhesive

Read Article

Featured Ads

Gluespec Poll

What level of expertise do you have in specialty chemicals like adhesives, sealants, conformal coatings, etc.?
Cure Temperature Test Methods
Cure Temperature Cure Time Test Method
25°C Functional cure
25°C Full cure
Cure Time Test Methods
Cure Time Test Method
Fast
10 to 20 min Functional cure
1,440 min Full cure
Fixture or Handling Strength Time Test Methods
Fixture or Handling Strength Time Fixture-Handling Strength Test Method Fixture-Handling Strength Time Temperature
0.33 to 0.83 min Curing 25°C
Viscosity Test Methods
Viscosity Temperature
600 to 1,000 cPs 25°C
Impact Strength Test Methods
Impact Strength Cure Temperature Test Method
Good
18 - 28 (kJ/ m2) 25°C Curing, ASTM D950
Tensile Strength Test Methods
Tensile Strength Cure Temperature Test Method
2,176 to 3,626 psi 25°C Curing, ISO 6922
3,626 to 5,076 psi 25°C Curing, DIN 53504
Shear Strength Test Methods
Shear Strength Cure Temperature Test Method
Good
2,901 to 4,351 psi 25°C Curing, ISO 4587
Elongation Test Methods
Elongation Test Method
20 to 50 % Curing, At break (DIN 53504)
