Wevo Casting Resin PD 445 Datasheet Wevo Casting Resin PD 445

CONTACT REP
Information provided by Gluespec

  • Description for Wevo Casting Resin PD 445

    Wevo Casting Resin PD 445 is a 2-Part Resin/Hardener Polyurethane Liquid used to Cast and Mold Glass, Metal and Plastic

    *See Terms of Use Below

    Chemical Resistance Outstanding Chemical Resistance
    Application Type Casting, Encapsulating
    1 Part or 2 Part 2-Part
    Material Form Liquid
    Substrate Glass, Metal, Plastic
    Industry Electrical and Electronic Components, Sensors, SMD-equipped PCBs
    Manufacturer Wevo
    Chemistry Polyurethane
    Cure Method Resin/Hardener, Room temperature cure
    Cure Temperature (°C) 25
    Cure Time (min) 720 to 1,440
    Viscosity (cPs) 1,800 to 2,200 (mPa·s)
    High Temperature Resistance (°C) 120
    Low Temperature Resistance (°C) -60
    Volume Resistivity (O) 4.2e14 (ohm •cm)

  • Technical Data for Wevo Casting Resin PD 445

    *See Terms of Use Below

    Overview
    • Chemical Resistance
      • Chemical Resistance - Outstanding Chemical Resistance
    • Application Type
    • 1 Part or 2 Part
      • 2-Part
    • Material Form
      • Liquid
    • Substrate
    • Industry
      • Electronics - Electrical and Electronic Components
      • Sensors
      • Printed Circuit Board (PCB) - SMD-equipped PCBs
    • Chemistry
    • Cure Method
      • Room Temperature / Air Dry - Room temperature cure
      • 2-Part Cure - Resin/Hardener
    Specifications
    Cure Specs
    Cure Temperature (°C) 25
    Cure Time (min) 720 to 1,440
    Viscosity (cPs) 1,800 to 2,200 (mPa·s) Test Method
    Linear Shrinkage (%) 0.60
    Work / Pot Time (min) 30 Test Method
    Mix Ratio 100:20 (by weight)
    Bond Strength
    General Bond Strength (psi) Very good adhesion
    Tensile Strength (psi) 1 (N/mm²) Test Method
    Material Resistance
    High Temperature Resistance (°C) 120
    Low Temperature Resistance (°C) -60
    Conductivity
    Dissipation Factor 0.01400 Test Method
    Dielectric Strength (V/mil) 20 (kV/mm) Test Method
    Dielectric Constant 3.00, Very low and stable Test Method
    Thermal Conductivity (W/m°K) 0.20 Test Method
    Surface Resistivity (O) > 10(16) (ohm) Test Method
    Volume Resistivity (O) 4.2e14 (ohm •cm) Test Method
    Hardness
    Shore A Hardness 25 to 30 Test Method
    Elongation (%) 140 Test Method
    Flexibility Highly flexible
    Modulus (psi) 2 (N/mm²) Test Method
    Other Properties
    Glass Transition Temp (Tg) (°C) -65 Test Method
    Coefficient of Thermal Expansion (CTE) 80 (ppm/K), 220 (ppm/K) Test Method
    Business Information
    Shelf Life Details Shelf life in original closed cans or drums, dry storage between 15°C and 25°C, 6 months.
    Shelf Life Temperature (°F) 59 to 77
    Shelf Life (mon) 6

  • Best Practices for Wevo Casting Resin PD 445

    *See Terms of Use Below

  • Comparable Materials for Wevo Casting Resin PD 445

    *See Terms of Use Below

    Spec Engine® Results

    • Resinlab
      EL420HD(Resinlab)

      A Two-part high hardness, room temperature curing polyurethane resin and Excellent long term UV stability.

    • Resinlab
      EL420OF(Resinlab)

      Two-component high hardness, room temperature curing polyurethane resin, Excellent long term UV stability, Encapsulation of LED arrays

    • Wevo
      Casting Resin PD 52(Wevo)

      Wevo Casting Resin PD 52 is a 2-Part Resin/Hardener Polyurethane Liquid used to Cast and Mold Glass, Metals and Plastic materials

    • Compare All
  Download Technical Data Sheet   Save This Material   Compare View Saved Items

Popular Articles

Characteristics of MMAs

Read Article

Testing the effectiveness of surface treatments

Read Article

Infographic: ENSURING A STRONG BOND - 6 Basic Methods of Surface Preparation

Read Article

The effectiveness of adhesives in the wind power industry

Read Article

Sponsored Articles

Unique Advantages of Contact Adhesives

Read Article

Using LOCTITE® 454™ is a Valid Option for Engineers Working with a Wide Variety of Materials

Read Article

Sylgard 184 by DOW is the Top Choice for a Transparent, Silicone Encapsulant. Read Why:

Read Article

Case Study: Creating reliable, corrosion-free bonds with LORD® 406 acrylic adhesive

Read Article

Featured Ads

Top Catalog Pages for Wevo Casting Resin PD 445

All Wevo Materials
View Now

Gluespec Poll

Who do you read or follow for engineering news and entertainment?
Viscosity Test Methods
Viscosity Temperature
1,800 to 2,200 (mPa·s) 22°C
Work / Pot Time Test Methods
Work / Pot Time Test Method Temperature
30 min 70g 25°C
Tensile Strength Test Methods
Tensile Strength Test Method
1 (N/mm²) ISO 527-2
Dielectric Constant Test Methods
Dielectric Constant Temperature Test Method
3.00 23°C at 50 Hz, IEC 60250 VDE 0303, TI.4
Very low and stable
Dielectric Strength Test Methods
Dielectric Strength Test Method
20 (kV/mm) IEC 60243-1 VDE 0303, TI.2
Dissipation Factor Test Methods
Dissipation Factor Temperature Test Method
0.01400 23°C at 50 Hz, IEC 60250 VDE 0303, TI.4
Surface Resistivity Test Methods
Surface Resistivity Temperature Test Method
> 10(16) (ohm) 23°C 50% r.h., IEC 60093 VDE 0303, TI.30
Thermal Conductivity Test Methods
Thermal Conductivity Test Method
0.20 W/m°K ISO 8894
Volume Resistivity Test Methods
Volume Resistivity Temp (°C) Test Method
4.2e14 (ohm •cm) 23°C 50% r.h., IEC 60093 VDE 0303, TI.30
Elongation Test Methods
Elongation Test Method
140 % at break, ISO 527-2
Modulus Test Methods
Modulus Test Method
2 (N/mm²) Elasticity, ISO 527-2
Shore A Hardness Test Methods
Shore A Hardness Shore Hardness Test Method
25 to 30 ISO 868, DIN 53505
Coefficient of Thermal Expansion (CTE) Test Methods
Coefficient of Thermal Expansion (CTE) CTE Temperature (°C) CTE Test Method
80 (ppm/K) <-70°C TMA
220 (ppm/K) >-60°C TMA
Glass Transition Temp (Tg) Test Methods
Glass Transition Temp (Tg) Glass Transition Temperature (Tg) Test Method
-65°C TMA
